MSI A520M-A PRO Socket AM4
433,20 lei
Asrock B550 Pro4 Socket AM4 ATX AMD B550
747,40 lei
Stoc epuizat
Informații suplimentare
| Producator |
Asrock |
|---|---|
| Cod Produs |
B550 PRO4 |
| Motherboard form factor |
ATX |
| BIOS type |
UEFI AMI |
| Audio output channels |
7.1 channels |
| RGB LED pin header |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| Ethernet interface type |
Gigabit Ethernet |
| Width |
305 mm |
| Supported storage drive interfaces |
M.2, Serial ATA III |
| Peripheral (Molex) power connectors (4-pin) |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Motherboard chipset |
AMD B550 |
| Memory slots type |
DIMM |
| Supported memory types |
DDR4-SDRAM |
| USB 2.0 connectors |
4 |
| HDMI ports quantity |
1 |
| Graphics card |
Radeon Vega |
| Wi-Fi |
No |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| Number of SATA III connectors |
6 |
| On-board graphics card |
Yes |
| Wake-on-LAN ready |
Yes |
| Supported memory clock speeds |
4333, 2667, 3733, 4400, 3866, 2933, 3600 MHz, 3466, 3200, 4266, 2133, 4200, 2400, 4133, 4000, 4533, 3800, 4466 |
| VGA (D-Sub) ports quantity |
1 |
| Maximum internal memory |
128 GB |
| HDCP |
Yes |
| Microphone in |
Yes |
| PS/2 ports quantity |
1 |
| 12V power connector |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Number of COM connectors |
1 |
| Drivers included |
Yes |
| Maximum number of SMP processors |
1 |
| Ethernet LAN |
Yes |
| Unbuffered memory |
Yes |
| Processor socket |
Socket AM4 |
| Motherboard chipset family |
AMD |
| CPU fan connector |
Yes |
| EPS power connector (8-pin) |
Yes |
| Memory channels |
Dual-channel |
| Number of memory slots |
4 |
| LAN controller |
Realtek RTL8111H |
| Compatible processor series |
3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 3 |
| DirectX version |
12.0 |
| Audio chip |
Realtek ALC1200 |
| Processor manufacturer |
AMD |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| Graphics card family |
AMD |
| Front panel audio connector |
Yes |
| Depth |
244 mm |
| ATX Power connector (24-pin) |
Yes |
