MSI PRO B760-P II motherboard Intel B760 LGA 1700 ATX
1.071,02 lei
20 în stoc
Informații suplimentare
| Producator |
MSI |
|---|---|
| Cod Produs |
7E29-002R |
| PCI Express x1 (Gen 4.x) slots |
2 |
| ECC сompatibility |
Non-ECC |
| Number of HDDs supported |
4 |
| Memory slots type |
DIMM |
| Supported memory types |
DDR5-SDRAM |
| PCI Express x16 (Gen 4.x) slots |
1 |
| Depth |
304.8 mm |
| Ethernet LAN |
Yes |
| Processor socket |
LGA 1700 |
| Number of memory slots |
4 |
| 12V power connector |
Yes |
| PCI Express x4 (Gen 4.x) slots |
1 |
| Maximum internal memory supported by processor |
256 GB |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Supported memory clock speed (max) |
7000 MHz |
| Number of SATA III connectors |
4 |
| Ethernet LAN (RJ-45) ports |
1 |
| Drivers included |
Yes |
| RAID levels |
5, 1, 10 |
| Front panel audio connector |
Yes |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Audio output channels |
7.1 channels |
| Cables included |
SATA |
| Memory channels |
Dual-channel |
| Number of M.2 (M) slots |
2 |
| DisplayPort version |
1.4 |
| Power fan connector |
Yes |
| Number of storage drives supported |
6 |
| Clear CMOS button |
Yes |
| Supported storage drive interfaces |
PCI Express 4.0, SATA III |
| RAID support |
Yes |
| LAN controller |
Realtek RTL8125-BG |
| Processor manufacturer |
Intel |
| USB 2.0 ports quantity |
4 |
| Compatible processor series |
Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Pentium® Gold, Intel® Core™ i3 |
| Wi-Fi |
No |
| Motherboard chipset family |
Intel |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
1 |
| Front panel connector |
Yes |
| Audio chip |
Realtek ALC897 |
| HDMI version |
2.1 |
| USB 2.0 connectors |
4 |
| Clear CMOS jumper |
Yes |
| DisplayPorts quantity |
1 |
| Motherboard chipset |
Intel B760 |
| S/PDIF out connector |
Yes |
| PCI Express x1 (Gen 3.x) slots |
1 |
| Supported memory clock speeds |
6800, 5000, 7000, 4800, 6400, 5800, 5400, 6200, 6600, 5200, 6000, 5600 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| ATX Power connector (24-pin) |
Yes |
| Chassis intrusion connector |
Yes |
| HDMI ports quantity |
1 |
| Width |
243.8 mm |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| CPU fan connector |
Yes |
| Unbuffered memory |
Yes |
| Motherboard form factor |
ATX |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
4 |
| Maximum internal memory |
256 GB |
| BIOS type |
UEFI AMI |
