Extralink SFP 1.25G | SFP WDM Module | 1,25Gbps, 1310/1550nm, single mode, 3km, SC, DOM, pair, dedicated for HP/Aruba

Single-mode SFP 1.25G 1310/1550NM module dedicated for HP/Aruba

The Extralink SFP 1.25G 1310/1550NM fiber-optic module is a single-mode SFP insert designed to transmit data at speeds up to 1.25 Gbps, providing a transmission range of up to 3 km. It has an LC output connector. The presented Extralink SFP 1.25G 1310/1550NM module is dedicated for HP/Aruba devices.

High-performance SFP module with WDM technology

The single-mode SFP module is compatible with SONET OC-24-LR-1 and the EU RoHS directive. Digital diagnostic monitoring allows for external and internal calibration. The device supports WDM signal multiplexing technology. The 1.25G SFP insert can be used in Gigabit Ethernet, fiber channels, switch-to-switch interfaces, switched backplane applications, router/server interfaces and other optical transmission systems.

Special features

Special features

• RoHS compliance
• Digital diagnostic monitoring – internal or external calibration
• Compatibility with SONET OC-24-LR-1
• Single 3.3 V AC adapter
• Dual data rate of 1.25 Gbps/1.063 Gbps
• Compatible with SFP MSA and SFF-8472 with SC/LC socket
• Range up to 3 m
• WDM technology
• HP/Aruba Compatibility
• Wavelengths – 1310 nm and 1550 nm
