LAN controller
| Intel® I219-LM |
Combo headphone/mic port
| Yes |
DisplayPort version
| 1.4a |
Processor model
| i5-14500 |
On-board graphics card model
| Intel UHD Graphics 770 |
DisplayPorts quantity
| 1 |
Wi-Fi
| No |
Audio system
| High Definition Audio |
Processor cores
| 14 |
Internal memory
| 16 GB |
Total storage capacity
| 512 GB |
Ethernet LAN data rates
| 1000 Mbit/s, 10, 100 |
Audio chip
| Realtek ALC3204 |
Product colour
| Black |
Storage temperature (T-T)
| -40 – 65 °C |
Cable lock slot type
| Kensington |
Trusted Platform Module (TPM)
| Yes |
Operating altitude
| -15.2 – 3048 m |
Operating temperature (T-T)
| 10 – 35 °C |
Internal memory type
| DDR5-SDRAM |
Ethernet LAN (RJ-45) ports
| 1 |
Number of SATA III connectors
| 2 |
Discrete graphics card model
| Not available |
USB 2.0 ports quantity
| 4 |
Processor manufacturer
| Intel |
On-board graphics card family
| Intel® UHD Graphics |
Maximum internal memory
| 64 GB |
Non-ECC
| Yes |
PCI Express x16 slots
| 1 |
Cables included
| AC |
Power supply
| 180 W |
Operating relative humidity (H-H)
| 20 – 80% |
Processor boost frequency
| 5 GHz |
Storage relative humidity (H-H)
| 5 – 95% |
Processor cache
| 24 MB |
Processor family
| Intel® Core™ i5 |
Chassis type
| Tower |
Processor threads
| 20 |
HDMI version
| 2.1 |
Optical drive type
| No |
Ethernet LAN
| Yes |
Discrete graphics card
| No |
Depth
| 293 mm |
On-board graphics card
| Yes |
Market positioning
| Business |
Cable lock slot
| Yes |
Product type
| PC |
Cabling technology
| 10/100/1000Base-T(X) |
PCI Express x1 slots
| 2 |
Operating system installed
| Windows 11 Pro |
Trial software
| Activate Your Microsoft 365 For A 30 Day Trial |
Processor cache type
| Smart Cache |
Height
| 324.3 mm |
Storage media
| SSD |
Width
| 154 mm |
HDMI ports quantity
| 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
| 3 |
On-board GPU manufacturer
| Intel |
Maximum turbo power
| 154 W |
Performance cores
| 6 |
Performance-core base frequency
| 2.6 GHz |
Sustainability certificates
| ENERGY STAR, EPEAT Gold, EPEAT Climate + |
Processor base power
| 65 W |
Efficient-core base frequency
| 1.9 GHz |
Number of front USB ports
| 4 |
Processor generation
| Intel® Core™ i5 (14th gen) |
Doesn't contain
| PVC/BFR |
Non-operating vibration
| 1.37 G |
Non-operating shock
| 105 G |
Number of rear USB ports
| 4 |
Number of SSDs installed
| 1 |
Efficient cores
| 8 |
PAIA version
| GaBi version 1, 2024 |
Memory layout (slots x size)
| 1 x 16 GB |
Display included
| No |
Non-operating altitude
| -15.2 – 10668 m |
Placement supported
| Vertical |
SSD capacity
| 512 GB |
Operating shock
| 40 G |
Carbon emissions, logistics (kg of CO2e)
| 10.126 |
Operating vibration
| 0.26 G |
Operating system architecture
| 64-bit |
Power supply input frequency
| 47/63 Hz |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
| 1 |
Number of front audio ports
| 1 |
Carbon emissions, energy usage (kg of CO2e)
| 45.65 |
Carbon emissions, end-of-life (kg of CO2e)
| 6.31 |
Carbon emissions, manufacturing (kg of CO2e)
| 103.75 |
Memory data transfer rate
| 4800 MT/s |
Total SSDs capacity
| 512 GB |
Power supply input voltage
| 90 – 264 V |
Number of processors installed
| 1 |
Memory slots
| 2x DIMM |
Trusted Platform Module (TPM) version
| 2.0 |
Total carbon footprint (kg of CO2e)
| 166 |
Efficient-core Max Turbo Frequency
| 3.7 GHz |
Performance-core Max Turbo Frequency
| 5 GHz |
